American gauge 120-347
Click to expand the criteria search box
American gauge 120-347 Filter Models: 5 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output current（mA） | Output voltage（V） | PF | Efficiency | Certificate | Spec. | Sample Application |
| PGAG040CXXXXVSLM1 | 40W | 120-347V | 900-1000mA | 30-42V | 0.9 | 0.84 | UL | - | |
| PGAG040C1000VSLM1 | 40W | 120-347V | 1000mA | 30-42V | 0.9 | 0.84 | UL | ||
| PGAG040C0950VSLM1 | 40W | 120-347V | 950mA | 30-42V | 0.9 | 0.84 | UL | ||
| PGAG040C0900VSLM1 | 40W | 120-347V | 900mA | 30-42V | 0.9 | 0.84 | UL | ||
| PGAG050CXXXXVSLM1 | 50W | 120-347V | 1050-1200mA | 30-42V | 0.9 | 0.84 | UL | - | |
| PGAG050C1200VSLM1 | 50W | 120-347V | 1200mA | 30-42V | 0.9 | 0.84 | UL | ||
| PGAG050C1150VSLM1 | 50W | 120-347V | 1150mA | 30-42V | 0.9 | 0.84 | UL | ||
| PGAG050C1100VSLM1 | 50W | 120-347V | 1100mA | 30-42V | 0.9 | 0.84 | UL | ||
| PGAG050C1050VSLM1 | 50W | 120-347V | 1050mA | 30-42V | 0.9 | 0.84 | UL | ||
| PGAG060CXXXXVSLM1 | 60W | 120-347V | 1250-1400mA | 30-42V | 0.9 | 0.85 | UL | - | |
| PGAG060C1400VSLM1 | 60W | 120-347V | 1400mA | 30-42V | 0.9 | 0.85 | UL | ||
| PGAG060C1350VSLM1 | 60W | 120-347V | 1350mA | 30-42V | 0.9 | 0.85 | UL | ||
| PGAG060C1300VSLM1 | 60W | 120-347V | 1300mA | 30-42V | 0.9 | 0.85 | UL | ||
| PGAG060C1250VSLM1 | 60W | 120-347V | 1250mA | 30-42V | 0.9 | 0.85 | UL | ||
| PGAG080CXXXXVSLM2 | 80W | 120-347V | 1500-1900mA | 30-42V | 0.9 | 0.88 | UL | - | |
| PGAG080C1900VSLM2 | 80W | 120-347V | 1900mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG080C1800VSLM2 | 80W | 120-347V | 1800mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG080C1700VSLM2 | 80W | 120-347V | 1700mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG080C1600VSLM2 | 80W | 120-347V | 1600mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG080C1500VSLM2 | 80W | 120-347V | 1500mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG100CXXXXVSLM2 | 100W | 120-347V | 2000-2400mA | 30-42V | 0.9 | 0.88 | UL | - | |
| PGAG100C2000VSLM2 | 100W | 120-347V | 2000mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG100C2100VSLM2 | 100W | 120-347V | 2100mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG100C2200VSLM2 | 100W | 120-347V | 2200mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG100C2300VSLM2 | 100W | 120-347V | 2300mA | 30-42V | 0.9 | 0.88 | UL | ||
| PGAG100C2400VSLM2 | 100W | 120-347V | 2400mA | 30-42V | 0.9 | 0.88 | UL |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
