American gauge 347-480

PGAM(30-50W)
PGAM(60-100W)
Click to expand the criteria search box
  • Product number

  • {/php}
  • Rated power(W)

  • Output current(mA)

  • Output voltage(V)

American gauge 347-480 Filter Models: 10 in total, please see the table below.

Series Rated power(W) Input voltage(V) Output current(mA) Output voltage(V) PF Efficiency Certificate Spec. Sample Application
PGAM040CXXXXVSLM2
40W 347-480V 900-1000mA 30-42V 0.9 0.86 UL
-
PGAM040C1000VSLM2
40W 347-480V 1000mA 30-42V 0.9 0.86 UL
PGAM040C0950VSLM2
40W 347-480V 950mA 30-42V 0.9 0.86 UL
PGAM040C0900VSLM2
40W 347-480V 900mA 30-42V 0.9 0.86 UL
PGAM050CXXXXVSLM2
50W 347-480V 1050-1200mA 30-42V 0.9 0.86 UL
-
PGAM050C1200VSLM2
50W 347-480V 1200mA 30-42V 0.9 0.86 UL
PGAM050C1150VSLM2
50W 347-480V 1150mA 30-42V 0.9 0.86 UL
PGAM050C1100VSLM2
50W 347-480V 1100mA 30-42V 0.9 0.86 UL
PGAM050C1050VSLM2
50W 347-480V 1050mA 30-42V 0.9 0.86 UL
PGAM060CXXXXVSLM2
60W 347-480V 1250-1400mA 30-42V 0.9 0.86 UL
-
PGAM060C1400VSLM2
60W 347-480V 1400mA 30-42V 0.9 0.86 UL
PGAM060C1350VSLM2
60W 347-480V 1350mA 30-42V 0.9 0.86 UL
PGAM060C1300VSLM2
60W 347-480V 1300mA 30-42V 0.9 0.86 UL
PGAM060C1250VSLM2
60W 347-480V 1250mA 30-42V 0.9 0.86 UL
PGAM040CXXXXVSLM2-AUX
40W 347-480V 900-1000mA 30-42V 0.9 0.85 UL
-
PGAM040C0900VSLM2-AUX
40W 347-480V 900mA 30-42V 0.9 0.85 UL
PGAM040C0950VSLM2-AUX
40W 347-480V 950mA 30-42V 0.9 0.85 UL
PGAM040C1000VSLM2-AUX
40W 347-480V 1000mA 30-42V 0.9 0.85 UL
PGAM050CXXXXVSLM2-AUX
50W 347-480V 1050-1200mA 30-42V 0.9 0.85 UL
-
PGAM050C1050VSLM2-AUX
50W 347-480V 1050mA 30-42V 0.9 0.85 UL
PGAM050C1100VSLM2-AUX
50W 347-480V 1100mA 30-42V 0.9 0.85 UL
PGAM050C1150VSLM2-AUX
50W 347-480V 1150mA 30-42V 0.9 0.85 UL
PGAM050C1200VSLM2-AUX
50W 347-480V 1200mA 30-42V 0.9 0.85 UL
PGAM060CXXXXVSLM2-AUX
60W 347-480V 1250-1400mA 30-42V 0.9 0.85 UL
-
PGAM060C1250VSLM2-AUX
60W 347-480V 1250mA 30-42V 0.9 0.85 UL
PGAM060C1300VSLM2-AUX
60W 347-480V 1300mA 30-42V 0.9 0.85 UL
PGAM060C1350VSLM2-AUX
60W 347-480V 1350mA 30-42V 0.9 0.85 UL
PGAM060C1400VSLM2-AUX
60W 347-480V 1400mA 30-42V 0.9 0.85 UL
PGAM080CXXXXVSLM3
80W 347-480V 1500-1900mA 30-42V 0.9 0.87 UL
-
PGAM080C1500VSLM3
80W 347-480V 1500mA 30-42V 0.9 0.87 UL
PGAM080C1600VSLM3
80W 347-480V 1600mA 30-42V 0.9 0.87 UL
PGAM080C1700VSLM3
80W 347-480V 1700mA 30-42V 0.9 0.87 UL
PGAM080C1800VSLM3
80W 347-480V 1800mA 30-42V 0.9 0.87 UL
PGAM080C1900VSLM3
80W 347-480V 1900mA 30-42V 0.9 0.87 UL
PGAM100CXXXXVSLM3
100W 347-480V 2000-2400mA 30-42V 0.9 0.87 UL
-
PGAM100C2000VSLM3
100W 347-480V 2000mA 30-42V 0.9 0.87 UL
PGAM100C2100VSLM3
100W 347-480V 2100mA 30-42V 0.9 0.87 -
PGAM100C2200VSLM3
100W 347-480V 2200mA 30-42V 0.9 0.87 UL
PGAM100C2300VSLM3
100W 347-480V 2300mA 30-42V 0.9 0.87 UL
PGAM100C2400VSLM3
100W 347-480V 2400mA 30-42V 0.9 0.87 UL
PGAM080CXXXXVSLM3-AUX
80W 347-480V 1500-1900mA 30-42V 0.9 0.86 UL
-
PGAM080C1500VSLM3-AUX
80W 347-480V 1500mA 30-42V 0.9 0.86 UL
PGAM080C1600VSLM3-AUX
80W 347-480V 1600mA 30-42V 0.9 0.86 UL
PGAM080C1700VSLM3-AUX
80W 347-480V 1700mA 30-42V 0.9 0.86 UL
PGAM080C1800VSLM3-AUX
80W 347-480V 1800mA 30-42V 0.9 0.86 UL
PGAM080C1900VSLM3-AUX
80W 347-480V 1900mA 30-42V 0.9 0.86 UL
PGAM100CXXXXVSLM3-AUX
100W 347-480V 2000-2400mA 30-42V 0.9 0.86 UL
-
PGAM100C2000VSLM3-AUX
100W 347-480V 2000mA 30-42V 0.9 0.86 UL
PGAM100C2100VSLM3-AUX
100W 347-480V 2100mA 30-42V 0.9 0.86 UL
PGAM100C2200VSLM3-AUX
100W 347-480V 2200mA 30-42V 0.9 0.86 UL
PGAM100C2300VSLM3-AUX
100W 347-480V 2300mA 30-42V 0.9 0.86 UL
PGAM100C2400VSLM3-AUX
100W 347-480V 2400mA 30-42V 0.9 0.86 UL

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
