IS Standard type (single phase) Filter Models: 8 in total, please see the table below.

Series Rated power(W) Input voltage(V) Output current(A) Output voltage(V) Efficiency Certificate Spec. Sample Application
IS15
15W 90-264V - 12V 15V 24V - -
-
IS15-12
15W 90-264V 1.20A 12V 80.0% UL UKCA FCC CB CE
IS15-15
15W 90-264V 1.00A 15V 83.0% UKCA CE
IS15-24
15W 90-264V 0.65A 24V 83.0% UL UKCA FCC CB CE
IS30
30W 90-264V - 5V 12V 15V 24V - -
-
IS30-5
25W 90-264V 5.00A 5V 78.0% UL UKCA FCC CB CE CUL
IS30-12
30W 90-264V 2.50A 12V 82.0% UL UKCA FCC CB CE CUL
IS30-15
30W 90-264V 2.00A 15V 83.0% UKCA CE
IS30-24
30W 90-264V 1.30A 24V 87.0% UL UKCA FCC CB CE CUL
IS50
50W 90-264V - 12V 24V 48V - -
-
IS50-12
50W 90-264V 4.20A 12V 81.0% UL UKCA FCC CB CE CUL
IS50-24
50W 90-264V 2.20A 24V 86.0% UL UKCA FCC CB CE CUL
IS50-48
50W 90-264V 1.10A 48V 87.0% UL UKCA FCC CB CE CUL
IS70
70W 90-264V - 12V 15V 24V 48V - -
-
IS70-12
60W 90-264V 5.00A 12V 84.0% UL UKCA FCC CB CE CUL
IS70-15
70W 90-264V 4.60A 15V 84.0% UKCA CE
IS70-24
70W 90-264V 3.00A 24V 86.0% UL UKCA FCC CB CE CUL
IS70-48
70W 90-264V 1.50A 48V 86.0% UL UKCA FCC CB CE CUL
IS120
120W 90-264V - 12V 15V 24V 48V - -
-
IS120-12
96W 90-264V 8.00A 12V 82.0% UL UKCA FCC CB CE
IS120-15
105W 90-264V 7.00A 15V 82.0% UKCA
IS120-24
120W 90-264V 5.00A 24V 85.0% UL UKCA FCC CB CE
IS120-48
120W 90-264V 2.50A 48V 86.0% UL UKCA FCC CB CE
IS180
180W 90-264V - 24V 48V - -
-
IS180-24
180W 90-264V 7.50A 24V 90.0% UL UKCA FCC CB CE CUL
IS180-48
180W 90-264V 3.80A 48V 91.0% UL UKCA FCC CB CE CUL
IS240
240W 90-264V - 24V 48V - -
-
IS240-24
240W 90-264V 10.00A 24V 90.0% UL UKCA FCC CB CE CUL
IS240-48
240W 90-264V 5.00A 48V 91.0% UL UKCA FCC CB CE CUL
IS480
480W 90-264V - 24V 48V - -
-
IS480-24
480W 90-264V 20.00A 24V 94.0% UL FCC CB CE CUL
IS480-48
480W 90-264V 10.00A 48V 94.0% UL FCC CB CE CUL

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
