High Power Inductor - New Energy

Product Selection >>
Loading

Lateral swipe →
Series DCR Load current Inductance Spec. Sample Application
FACM40253BH
1.7-14.0mΩ 10.0-35.0A 2.8-25.0mH
-
FACM40253BH-253Y10R0
14 10 25 -
FACM40253BH-203Y13R0
9.5 13 20 -
FACM40253BH-143Y16R0
6.2 16 14 -
FACM40253BH-552Y20R0
3.5 20 5.5 -
FACM40253BH-402Y28R0
2.5 28 4 -
FACM40253BH-282Y35R0
1.7 35 2.8 -
FACM40323BV
2.0-16.0mΩ 10.0-30.0A 2.7-20.0mH
-
FACM40323BV-203Y10R0
16 10 20 -
FACM40323BV-153Y13R0
12 13 15 -
FACM40323BV-123Y16R0
7.5 16 12 -
FACM40323BV-552Y20R0
4.5 20 5.5 -
FACM40323BV-442Y25R0
3 25 4.4 -
FACM40323BV-272Y30R0
2 30 2.7 -
FACM40243BV
1.7-13.0mΩ 10.0-35.0A 0.35-3.0mH
-
FACM40243BV-302Y10R0
13 10 3 -
FACM40243BV-232Y13R0
9 13 2.3 -
FACM40243BV-162Y16R0
5.5 16 1.6 -
FACM40243BV-681Y23R0
3 23 0.68 -
FACM40243BV-501Y28R0
2.2 28 0.5 -
FACM40243BV-351Y35R0
1.7 35 0.35 -
FACM46273BH
1.4-14.0mΩ 10.0-40.0A 2.5-17.0mH
-
FACM46273BH-173Y10R0
14 10 17 -
FACM46273BH-143Y13R0
9.3 13 14 -
FACM46273BH-103Y16R0
6.2 16 10 -
FACM46273BH-802Y20R0
4.7 20 8 -
FACM46273BH-602Y25R0
3.3 25 6 -
FACM46273BH-502Y28R0
2.6 28 5 -
FACM46273BH-352Y32R0
2 32 3.5 -
FACM46273BH-252Y40R0
1.4 40 2.5 -
FACM46273BV
1.4-14.0mΩ 10.0-40.0A 2.5-17.0mH
-
FACM46273BV-173Y10R0
14 10 17 -
FACM46273BV-143Y13R0
9.3 13 14 -
FACM46273BV-103Y16R0
6.2 16 10 -
FACM46273BV-802Y20R0
4.7 20 8 -
FACM46273BV-602Y25R0
3.3 25 6 -
FACM46273BV-502Y28R0
2.6 28 5 -
FACM46273BV-352Y32R0
2 32 3.5 -
FACM46273BV-252Y40R0
1.4 40 2.5 -
FACM50403BH
0.4-7.0mΩ 20.0-100.0A 0.5-14.0mH
-
FACM50403BH-143Y20R0
7 20 14 -
FACM50403BH-822Y25R0
4.5 25 8.2 -
FACM50403BH-582Y30R0
3.2 30 5.8 -
FACM50403BH-272Y40R0
1.8 40 2.7 -
FACM50403BH-202Y50R0
1.2 50 2 -
FACM50403BH-152Y60R0
0.85 60 1.5 -
FACM50403BH-501Y100R0
0.4 100 0.5 -
FACM60453BH
0.4-7.0mΩ 20.0-100.0A 0.5-14.0mH
-
FACM60453BH-143Y20R0
7 20 14 -
FACM60453BH-822Y25R0
4.5 25 8.2 -
FACM60453BH-582Y30R0
3.2 30 5.8 -
FACM60453BH-272Y40R0
1.8 40 2.7 -
FACM60453BH-202Y50R0
1.2 50 2 -
FACM60453BH-152Y60R0
0.85 60 1.5 -
FACM60453BH-501Y100R0
0.4 100 0.5 -
FACM60453BH-132Y100R0
0.5 100 1.3 -
FACM50353C
4.0-9.0mΩ 16.0-25.0A 0.5-18.0mH
-
FACM50353C-183Y16R0
9 16 18 -
FACM50353C-143Y20R0
7 20 14 -
FACM50353C-103Y20R0
5.5 20 10 -
FACM50353C-822Y20R0
6 20 8.2 -
FACM50353C-682Y25R0
4.5 25 6.8 -
FACM50353C-502Y25R0
4 25 5 -
FACM50353C-302Y16R0
8 16 3 -
FACM50353C-202Y16R0
8 16 2 -
FACM50353C-152Y20R0
5.5 20 1.5 -
FACM50353C-152Y16R0
8 16 1.5 -
FACM50353C-122Y20R0
5.5 20 1.2 -
FACM50353C-102Y16R0
8 16 1 -
FACM50353C-851Y20R0
5.5 20 0.85 -
FACM50353C-681Y25R0
4 25 0.68 -
FACM50353C-681Y20R0
5.5 20 0.68 -
FACM50353C-501Y25R0
4 25 0.5 -
FACMxxBV
- - - -
-
FACMxxBH
- - - -
-
FACMxxxBH
- - - -
-
FACMxx3BH
- - - -
-
FABL001H
7.8mΩ 40.0/50.0A 310μH
-
FABL001H-1
7.8mΩ 40.0/50.0A 310μH
FABL002V
7.8mΩ 40.0/50.0A 310μH
-
FABL002V-1
7.8mΩ 40.0/50.0A 310μH
FABL003H
11.8mΩ 33.0/42.0A 220μH
-
FABL003H-1
11.8mΩ 33.0/42.0A 220μH
FABL004H
5.7mΩ 60.0/74.0A 100μH
-
FABL004H-1
5.7mΩ 60.0/74.0A 100μH
FABL005H
7.0mΩ 63.0/79.0A 120μH
-
FABL005H-1
7.0mΩ 63.0/79.0A 120μH
FABL006H
4.7mΩ 80.0/100.0A 200μH
-
FABL006H-1
4.7mΩ 80.0/100.0A 200μH
FABL007V
1.7mΩ 100.0/120.0A 60μH
-
FABL007V-1
1.7mΩ 100.0/120.0A 60μH
FABL008V
- - - -
-
FABL009H
- - - -
-
FARTC-H
1.7-3.5mΩ 30.0-50.0A 3.3-10.0μH
-
FARTC-100J30R0H
3.5 30 10
FARTC-8R2J30R0H
3.5 30 8.2
FARTC-6R8J30R0H
3.5 30 6.8
FARTC-5R6J35R0H
3.5 35 5.6
FARTC-4R7J35R0H
3.5 35 4.7
FARTC-3R9K35R0H
3.5 35 3.9
FARTC-3R3K35R0H
3.5 35 3.3
FARTC-5R6J40R0H
1.7 40 5.6
FARTC-4R7J45R0H
1.7 45 4.7
FARTC-3R9K50R0H
1.7 50 3.9
FARTC-3R3K50R0H
1.7 50 3.3
FARTC-V
1.7-3.5mΩ 30.0-50.0A 3.3-10.0μH
-
FARTC-100J30R0V
3.5 30 10
FARTC-8R2J30R0V
3.5 30 8.2
FARTC-6R8J30R0V
3.5 30 6.8
FARTC-5R6J35R0V
3.5 35 5.6
FARTC-4R7J35R0V
3.5 35 4.7
FARTC-3R9K35R0V
3.5 35 3.9
FARTC-3R3K35R0V
3.5 35 3.3
FARTC-5R6J40R0V
1.7 40 5.6
FARTC-4R7J45R0V
1.7 45 4.7
FARTC-3R9K50R0V
1.7 50 3.9
FARTC-3R3K50R0V
1.7 50 3.3

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
