SMD Bobbin
Click to expand the criteria search box
SMD Bobbin Filter Models: 10 in total, please see the table below.
| Series | Spec. | Material | Row pitch | Pin Pitch | Spec. | Sample Application |
| SMD-EE | MORE | - | - | - | - | - |
| SMD-EE5.0-CAP | EE5.0 CAP | LCP-E4008 | - | - | ||
| SMD-EE-0501 | EE5.0(3+3P)-1S | PM9630 | 6.60mm | 1.86mm | ||
| SMD-EE-0502 | EE5.0(3+3P)-1S | PM9630 | 6.60mm | 1.86mm | ||
| SMD-EE-0503 | EE5.0(3+3P)-2S | LCP-E4008 | 6.60mm | 1.86mm | ||
| SMD-EE-0801 | EE8.3(3+3P)-1S | PM9630 | 10.00mm | 2.50mm | ||
| SMD-EE-0803 | EE8.3(4+4P)-1S | PM9630 | 10.20mm | 2.54mm | ||
| SMD-EE-0803C | EE8.8 CAP | LCP-E4008 | - | - | ||
| SMD-EE-0804 | EE8.3(4+4P)-1S | PM9630 | 10.20mm | 2.54mm | ||
| SMD-EE-1001 | EE10(5+5 PIN)-1S | PHENOLIC | 13.70mm | 2.50mm | ||
| SMD-EE-1301 | EE8.8(4+4P)-1S | PA66(Black) | 14.60mm | 2.50mm | ||
| SMD-EE-1301C | EE13 CAP | PA66(Black) | - | - | ||
| SMD-EE-1602 | EE16(5+5 PIN)-1S | PHENOLIC | 21.15mm | 3.25mm | ||
| SMD-EE-1602C | EE16 CAP | PET | - | - | ||
| SMD-EF | MORE | - | - | - | - | - |
| SMD-EF-1201 | EF12.6(5+5P)-1S | PM9630 | 15.30mm | 2.54mm | ||
| SMD-EF-1202 | EF12.6(5+5P)-2S | PM9630 | 15.30mm | 2.54mm | ||
| SMD-EF-1202-1 | EF12.6(5+5P)-2S | PM9630 | 15.30mm | 2.54mm | ||
| SMD-EF-1203 | EF12.6(5+5P)-1S | PM9630 | 15.30mm | 2.54mm | ||
| SMD-EF-1601 | EF16(6+6P)-1S | PM9630 | 23.10mm | 2.54mm | ||
| SMD-EF-1601C | EF16 CAP | LCP-E4008 | - | - | ||
| SMD-EFD | MORE | - | - | - | - | - |
| SMD-EFD-1001 | EFD10(4+4P)-1S | PM9630 | 15.60mm | 3.00mm | ||
| SMD-EFD-1201 | EFD12(4+4P)-1S | PM9630 | 17.00mm | 3.00mm | ||
| SMD-EFD-1501 | EFD15(5+5P)-1S | PM9630 | 18.30mm | 2.50mm | ||
| SMD-EFD-1502 | EFD15(5+5P)-4S | LCP-E4008 | 21.35mm | 2.50mm | ||
| SMD-EFD-1503 | EFD15(5+5P)-1S | PM9630 | 18.30mm | 2.50mm | ||
| SMD-EFD-1504 | EFD15(6+6P)-1S | PM9630 | 18.10mm | 2.50mm | ||
| SMD-EFD-1505 | EFD15(5+5P)-1S | PM9630 | 24.20mm | 2.50mm | ||
| SMD-EFD-1506 | EFD15(5+5P)-1S | PM9630 | 18.30mm | 2.50mm | ||
| SMD-EFD-1506-1 | EFD15(5+5P)-1S | PM9630 | 18.30mm | 2.50mm | ||
| SMD-EFD-1507 | EFD15(8+8P)-1S | PM9630 | 18.10mm | 2.00mm | ||
| SMD-EFD-1508 | EFD12(4+4P)-1S | PHENOLIC | 19.20mm | 3.75mm | ||
| SMD-EFD-1701 | EFD17(6+6P)-1S | PM9630 | 20.50mm | 2.54mm | ||
| SMD-EFD-2001 | EFD20(8+8P)-1S | PM9630 | 24.60mm | 3.00mm | ||
| SMD-EFD-2002 | EFD20(5+5P)-1S | PM9630 | 23.10mm | 3.76mm | ||
| SMD-EFD-2002-1 | EFD20(5+5P)-1S | PM9630 | 25.00mm | 3.70mm | ||
| SMD-EFD-2004 | EFD20(6+6P)-1S | PM9630 | 24.60mm | 3.00mm | ||
| SMD-EFD-2004-1 | EFD20(6+6P)-1S | PM9630 | 24.60mm | 3.00mm | ||
| SMD-EFD-2005 | EFD20(5+5P)-1S | PHENOLIC | 24.50mm | 3.76mm | ||
| SMD-EFD-2006 | EFD20(5+5P)-1S | PM9820 | 25.10mm | 3.76mm | ||
| SMD-EFD-2501 | EFD25(5+5P)-1S | PM9630 | 31.50mm | 5.00mm | ||
| SMD-EFD-2503 | EFD25(6+6P)-1S | PM9630 | 29.70mm | 4.00mm | ||
| SMD-EFD-2504 | EFD25(6+6P)-1S | PM9630 | 29.40mm | 3.75mm | ||
| SMD-EFD-3001 | EFD30(6+6P)-1S | PM9630 | 31.60mm | 5.00mm | ||
| SMD-EP | MORE | - | - | - | - | - |
| SMD-EP-0501 | EP5(4+4P)-1S | PM9630 | 5.10mm | 1.90mm | ||
| SMD-EP-0502 | EP5(3+3P)-1S | PM9630 | 7.70mm | 1.85mm | ||
| SMD-EP-0503 | EP5(3+3P)-1S | PM9630 | 5.30mm | 2.25mm | ||
| SMD-EP-0704 | EP7(4+4P)-1S | PM9630 | 10.80mm | 2.50mm | ||
| SMD-EP-0705 | EP7(4+4P)-1S | PM9630 | 5.60mm | 2.50mm | ||
| SMD-EP-0706 | EP7(3+3P)-1S | PM9630 | 10.60mm | 2.50mm | ||
| SMD-EP-1001 | EP10(4+4P)-1S | PM9630 | 14.60mm | 2.50mm | ||
| SMD-EP-1301 | EP13(5+5P)-1S | PM9630 | 15.40mm | 2.50mm | ||
| SMD-EP-1302 | EP13(4+8P)-1S | PM9630 | 16.40mm | - | ||
| SMD-EP-1303 | EP13(4+8P)-1S | PM9630 | 16.40mm | - | ||
| SMD-EP-1304 | EP13(5+5P)-1S | PM9630 | 12.50mm | 2.50mm | ||
| SMD-EP-1305 | EP13(4+8P)-1S | PM9630 | 12.50mm | - | ||
| SMD-EP-1305-1 | EP13(4+8P)-1S | PM9630 | 12.50mm | - | ||
| SMD-EP-1305-2 | EP13(8+8P)-1S | PM9630 | 16.00mm | 1.70mm | ||
| SMD-EP-1306 | EP13(6+6P)-1S | PM9630 | 9.90mm | 2.00mm | ||
| SMD-EP-1307 | EP13(5+5P)-1S | LCP-E4008 | 17.00mm | 2.50mm | ||
| SMD-EPC | MORE | - | - | - | - | - |
| SMD-EPC-1001 | EPC10(4+4P)-1S | PM9630 | 11.50mm | 2.00mm | ||
| SMD-EPC-1301 | EPC13(5+5P)-1S | PHENOLIC | 17.20mm | 2.50mm | ||
| SMD-EPC-1302 | EPC13(5+5P)-4S | LCP-E4008 | 17.20mm | 2.50mm | ||
| SMD-EPC-1303 | EPC13(5+5P)-5S | LCP-E4008 | 17.20mm | 3.00mm | ||
| SMD-EPC-1304 | EPC13(5+5P)-1S | PHENOLIC | 17.20mm | 3.00mm | ||
| SMD-EPC-1701 | EPC17(4+5P)-1S | PM9820 | 20.8mm | - | ||
| SMD-EPC-1902 | EPC19(6+6P)-1S | LCP-E4008 | 21.90mm | 2.50mm | ||
| SMD-EPC-1903 | EPC19(6+4P)-1S | LCP-E4008 | 24.10mm | - | ||
| SMD-EPC-2501 | EPC25(5+6P)-1S | PM9630 | 26.30mm | - | ||
| SMD-EPC-2501-1 | EPC25(5+6P)-1S | PM9630 | 28.70mm | - | ||
| SMD-ER | MORE | - | - | - | - | - |
| SMD-ER-0701 | ER7.5(4+4P)-1S | PM9630 | 7.80mm | 1.75mm | ||
| SMD-ER-0901 | ER9.5(4+4P)-1S | PM9630 | 7.80mm | 1.75mm | ||
| SMD-ER-1101 | ER11.5(4+4P)-1S | PM9630 | 11.00mm | 2.00mm | ||
| SMD-ER-1102 | ER11.5(4+4P)-1S | PM9630 | 11.00mm | 2.00mm | ||
| SMD-ER-1103 | ER11.5(4+4P)-1S | PM9630 | 11.00mm | 2.00mm | ||
| SMD-ER-1104 | ER11.5(6+6P)-1S | PM9630 | 11.00mm | 2.00mm | ||
| SMD-ER-1201 | ER12(6+6P)-1S | PM9630 | 16.80mm | 2.00mm | ||
| SMD-RM | MORE | - | - | - | - | - |
| SMD-RM-0501 | RM5(4+4P)-1S | LCP-E4008 | 16.00mm | 3.81mm | ||
| SMD-RM-0501-1 | RM5(4+4P)-1S | LCP-E4008 | 16.60mm | 3.81mm | ||
| SMD-RM-0502 | RM5(4+4P)-1S | PM9630 | 15.20mm | 3.75mm | ||
| SMD-RM-0601 | RM6(4+4P)-1S | PM9630 | 14.70mm | 3.80mm | ||
| SMD-RM-0602 | RM6(4+4P)-2S | PM9630 | 14.70mm | 3.80mm | ||
| SMD-RM-0603 | RM6(4+4P)-1S | LCP-E4008 | 18.00mm | - | ||
| SMD-RM-0603-1 | RM6(4+4P)-2S | LCP-E4008 | 18.00mm | - | ||
| SMD-RM-0603-2 | RM6(4+4P)-1S | PM9630 | 17.80mm | - | ||
| SMD-ED | MORE | - | - | - | - | - |
| SMD-ED-0801 | ED8(2+2P)-1S | LCP-E4008 | 8.00mm | 2.72mm | ||
| SMD-ED-0802 | ED8(3+3P)-1S | LCP-E4008 | 8.00mm | 2.72mm | ||
| SMD-CUT | MORE | - | - | - | - | - |
| SMD-CUT-1403 | CUT14*8(4+4P)-1S | LCP-E4008 | 8.00mm | 2.72mm | ||
| SMD-ERI | MORE | - | - | - | - | - |
| SMD-ERI-7.5 | ERI-7.5(4+4P)-1S | PM9630 | 8.000mm | 1.72mm |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
