PIS Professional (Single-Phase)

PIS30
PIS50
PIS75
PIS120
Click to expand the criteria search box
  • Product number

  • {/php}
  • Rated power(W)

  • Input voltage(V)

  • Output current(A)

  • Output current(mA)

  • Output voltage(V)

  • Efficiency

  • PFC function

  • DC-OK

  • Certificate

  • Spec.

  • Ripple and noise

  • Series

PIS Professional (Single-Phase) Filter Models: 4 in total, please see the table below.

Series Rated power(W) Input voltage(V) Output current(A) Output voltage(V) Efficiency PFC function DC-OK Certificate Spec. Sample Application
PIS30
30 90-264 - 5 12 24 - NO NO UL UKCA SAA TUV CB CE
-
PIS30-5
25 90-264 5 5 85% NO NO UL UKCA SAA TUV CB CE -
PIS30-12
30 90-264 2.5 12 88% NO NO UL UKCA SAA TUV CB CE -
PIS30-24
30 90-264 1.3 24 89% NO NO UL UKCA SAA TUV CB CE -
PIS50
50 90-264 - 12 24 48 - NO NO UL UKCA SAA TUV CB CE
-
PIS50-12
50 90-264 4.2 12 81% NO NO UL UKCA SAA TUV CB CE -
PIS50-24
50 90-264 2.1 24 86% NO NO UL UKCA SAA TUV CB CE -
PIS50-48
50 90-264 1.1 48 87% NO NO UL UKCA SAA TUV CB CE -
PIS75
70 90-264 - 12 24 48 - NO NO UL UKCA SAA TUV CB CE
-
PIS75-12
60 90-264 6.3 12 89% NO NO UL UKCA SAA TUV CB CE -
PIS75-24
70 90-264 3.2 24 89% NO NO UL UKCA SAA TUV CB CE -
PIS75-48
70 90-264 1.6 48 90% NO NO UL UKCA SAA TUV CB CE -
PIS120
120 90-264 - 12 24 48 - NO YES UL UKCA SAA TUV CB CE
-
PIS120-12
96 90-264 10 12 86% NO YES UL UKCA SAA TUV CB CE -
PIS120-24
120 90-264 5 24 88% NO YES UL UKCA SAA TUV CB CE -
PIS120-48
120 90-264 2.5 48 89% NO YES UL UKCA SAA TUV CB CE -

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
